Double Eccentric structure ensures low operating torques with zero leakage performance.
Inner and outer surfaces of the valve are coated with average 250 microns thickness of fusion bonded epoxy. (FBE) min 300micron available upon request.
Higher thicknesses are available upon request.
Low moments are obtained by decreasing the friction through self-lubricating bushings.
Can bear high stretching stresses on the pipeline through the ductile iron body and disc
High impact resistance.
Reduces the pressure loss through the disc designed in accordance with the direction of flow
Pressure loss is at minimum level by double shaft design.
Sealing gaskets made of EPDM (default), NBR or VITON supplied according to operating conditions and demand can be disassembled and replaced easily in field conditions.
With the o-rings on the bearing bushings, disc pin holes are protected against corrosion (Dry shaft)
Retaining ring is assembled to the disc with imbus bolts, the disc is protected against corrosion by placing o-rings under the bolts.
Through the gearbox assembled on top flange, it maintains openning/closing the valve with very low torques.
Lifting lugs and feet ease the weight balance during transport and installation.
With the stainless steel welding, in the valve will have higher sealing resistance.
