Normal Working Conditions
7 Bar inlet pressure
35 °C inlet temperature
%100 inlet air relative humidity
Normal pressurized dew point is -40°C, Maximum working pressure 12 bar (g)
Principles of Operation
A centrifugal blower and high efficiency heater elliminates the use of valuable compressed air to be used for dessicant regeneration. The completely automatic drying system uses blower to pull ambient air and pass it through the heater. This hot air stream flows opposite of the drying flow direction. Hot air above 200°C rgenerates the moisture inside dessicant bed and strips it completely of all moisture. The advanced control system monitors the dew point adjust the heating / regeneration accordingly thereby providing valuable energy savings. The heater circuit is completely insulated ensuring maximum heating efficiency.
Dew point monitoring & control.
Computer controlled – Display Status
Display of Alarms – Display of Pressure
Remote Start-Stop – Low Pressure Alarm.
Minimum Pressure monitoring valve.
High pressure switches and alarms.
The functions of externally heated and heatless dryers have been integrated to the YBD Dryer.
